Marker Posts and Plates
Precast concrete Marker post are widely used by utility companies and are installed to assist the location and identification of underground services.
Marker posts are made from reinforced precast concrete, manufactured and tested to BS 1881 standards and are available in a variety of types and sizes.
Available Post Types
We manufacture several standard marker posts in accordance with BS 1881, Marker posts are available with or without anchor bases.
Hydrant posts have preformed holes to accept plates within.
| Width (mm) | Depth (mm) | Height (mm) | Unit Weight (kg) | Pack Quantity |
|---|---|---|---|---|
| 135 | 75 | 1065 | 24 | 50 |
| 100 | 100 | 1525 | 49 | 1 |
| Width (mm) | Depth (mm) | Height (mm) | Unit Weight (kg) | Pack Quantity |
|---|---|---|---|---|
| 100 | 100 | 1000 | 34 | 50 |
| 100 | 100 | 1000 | 17 | 50 |
| Width (mm) | Depth (mm) | Height (mm) | Unit Weight (kg) | Pack Quantity |
|---|---|---|---|---|
| 1065 | 25 | 40 |
| Width (mm) | Depth (mm) | Height (mm) | Unit Weight (kg) | Pack Quantity |
|---|---|---|---|---|
| 100 | 75 | 726 | 24 | 1 |
| Width (mm) | Depth (mm) | Height (mm) | Unit Weight (kg) | Pack Quantity |
|---|---|---|---|---|
| 250 | 100 | 1000 | 50 | 30 |
Available Marker Plate Types
Marker plates are fixed to the posts to give further information on what the post is actually marking. They come in a variety of colours and can have as much or as little information as the client requires. As standard the plates have H, SV AV for the Water Industry and HV CABLES for the Power and Rail Industry.
